Showing 49–64 of 107 results
REAR TOW HITCH (attachment for SNO-MASTER 48 or 72)
$100.00SNO MASTER Rear Tow Hitch
SNO-MASTER Rear Hitch attaches quickly to the rear of the SNO-MASTER 48 and 72 Chassis using the included 4 – 1/4-20 x 7/8″ Stainless Steel Hex Bolts and 4 – 1/4-20 Stainless Steel Nylock Nuts. Each SNO-MASTER chassis includes the pre-drilled holes (some located behind the sticker) to attach the Rear Hitch on the left, right, or center of the groomed trail. The Stainless Steel Pin enables the 180 degree vertical movement needed to attach the Pin Coupler of the TRAKOR.
- Material: Pin-Stainless Steel, Hitch-Carbon Steel
- Finish: Bengal Black Powder Coated Paint
Ring Coupler
Original price was: $130.00.$90.00Current price is: $90.00.
Ring Coupler – 3″ Offset
Original price was: $140.00.$100.00Current price is: $100.00.
Ring Coupler – 5″ Offset
Original price was: $150.00.$110.00Current price is: $110.00.Ring Coupler – 5″ Offset
Ring coupler used to connect towing machine to snow groomer. The ring coupler allows for variable movement when linked to a Pintle Hook hitch. Includes a 5″ x 3/4″ rectangle tube offset to raise or lower the connection point.
- Measurements – 3/4″ x 6″ (11 GA) + 3/8″ 2-3/4″ Ring
- Finish – Bengal Black powder coated paint
Shear Nose Guard
$30.00Shear Nose Guard
Measurement: Approximately 6-1/2″ x 2″
Material: 12 GA Stainless Steel
Finish: #4 Stainless Surface on leading side
Shear Pin Upgrade Kit
$15.00Shear Pin Upgrade Kit
Upgrade your current Snow Groomers Hitch Plate and Coupler (Pin or Ring) with a 750 ft-lb. break rating. With the included 13/64″ drill bit, drill through the existing shear pin holes in both the coupler and hitch plate receiver then insert the new 3/16″ Zinc Yellow-Chromate plated Wire-Lock Shear Pin.
SLED Universal Hitch
$160.00SLED Universal Hitch
Fits most snowmobile rear bumper bars and many ATV rear bumper bars. Easy to install, with no tools required and adjusts to fit 12-1/4″ to 20″ openings on bumper bars of 1″ up to 2-1/4″. Eliminate the side to side movement as seen with other bolt on hitches. Made of 10 GA steel plate and powder coated for long durability and rust protection. All hardware is made of stainless steel. Connect your snow grooming equipment using the standard pin coupler included in all of our pin type groomer bundles.
SM48 Drawbars (LH and RH)
$750.00SNO MASTER 48 Drawbars
Measurement: Approximately 1″ x 2″ x 82″
Material: 11 GA Standard Steel Rectangle Tube
Finish: Bengal Black Powder Coat paint
Includes: (1) Left Hand SM48 Drawbar, (1) Right Hand SM48 Drawbar, (2) .125″ x 1-15/16″ Stainless Steel Hitch Pins, (2) 1/2″ Zinc plated Washer
SM48 Hitch Plate Assembly
$90.00SNO MASTER 48 Hitch Plate Assembly
Measurement: 6-1/2″ x 8-1/4″
Material: 12 GA Carbon Steel Plate
Finish: Bengal Black Powder Coat Paint
Includes: (1) Upper Hitch Plate w/ Receiver, (1) Lower Hitch Plate, (4) 5/16-18 x 3″ Stainless Steel Carriage Bolts, (4) 5/16-18 Stainless Steel Nylock Nuts, (1) Anti-Seize Packet
SM48 Sub-Frame
$400.00SNO MASTER 48 Sub Frame
Measurement: Approximately 1-1/2″ x 14-1/2″ x 49″
Material: 1″ x 1-1/2″ 11 GA Rectangle Tubing, 7 GA Standard Steel plate
Finish: Bengal Black Powder Coat paint
Includes: (1) SM48 Sub-Frame, (4) 3/8-16 x 1-3/4″ Stainless Steel Hex Bolt, (4) 3/8-16 Stainless Steel Nylock Nuts
SM48 Weight/Bow Cover Set (1 Left, 1 Right)
$50.00SM48 Weight and Bow Cover Set
Measurement: Approximately 24″ x 13-1/2″
Material: .125 ABS
Finish: Black ABS, Haircell outward side, smooth inward side
Includes: (2) 24″ Weight and Bow Covers, (14) #68 Pop Rivets
SM72 Drawbars (LH and RH) w/Sub-Frame & Hitch Plate Assembly
$1,400.00SM72 Drawbars (LH and RH) w/Sub-Frame & Hitch Plate Assembly
Measurement: Approximately 1″ x 2″ x 82″
Material: 11 GA Standard Steel Rectangle Tube
Finish: Bengal Black Powder Coat paint
Includes: (1) Left Hand SM72 Drawbar, (1) Right Hand SM72 Drawbar, (2) .125″ x 1-15/16″ Stainless Steel Hitch Pins, (2) 1/2″ Zinc plated Washer
SM72 Hitch Plate Assembly
$120.00SNO MASTER 72 Hitch Plate Assembly
Measurement: Approximately 7-1/4″ x 11″
Material: 12 GA Carbon Steel Plate
Finish: Bengal Black Powder Coat Paint
Includes: (4) 5/16-18 x 3″ Stainless Steel Carriage Bolts, (4) 5/16-18 Stainless Steel Nylock Nuts, (1) Anti-Seize Packet
SM72 Sub-Frame
$500.00SNO MASTER 72 Sub Frame
Measurement: Approximately 2″ x 14″ x 73″
Material: 1″ x 2″ 11 GA Rectangle Tubing, 7 GA Standard Steel plate
Finish: Bengal Black Powder Coat paint
Includes: (1) SM72 Sub-Frame, (4) 3/8-16 x 1-3/4″ Stainless Steel Hex Bolt, (4) 3/8-16 Stainless Steel Nylock Nuts
